Heat Shrink Printable Tubing
Insutek HSPT Series of Heat Shrink Printable Tubing, is made from high-quality irradiated cross-linked polyolefin material, it has superior electrical, physical, chemical, and printing properties, making it suitable for direct printing by identification printers and ensuring long-lasting markings.
Features
Shrinkage ratio: 2:1, 3:1
Soft and highly flame-retardant
Applicable temperature range: -55 ℃ -135 ℃;
Initial shrinkage temperature: 70 ℃
Complete shrinkage temperature: 110 ℃
Rohs Reach Certified
Related products
No data
The printable tubing is specifically designed for high-performance wire and cable marking and labeling, ideal solution for aerospace, military, ship building industry application.
|
Item |
Test methods |
Specifications |
|
Tensile Strength |
SAE-AMS-DTL-23053 |
≥10.3MPa |
|
Ultimate Elongation |
SAE-AMS-DTL-23053 |
≥200% |
|
Flexibility |
SAE-AMS-DTL-23053.4.6.7 |
-55℃±1℃, 4h, No cracking |
|
Heat Shock |
SAE-AMS-DTL-23053.4.6.8 |
250℃±3℃, 4h, No cracking, dripping, flowing |
|
Aging Performance |
SAE-AMS-DTL-23053.4.6.9 |
175℃±2℃, 168h, No visual damage |
|
Tensile Strength After Aging |
SAE-AMS-DTL-23053.4.6.13 and ASTM D638 |
≥6.9MPa，23℃±2℃ |
|
Ultimate Elongation After Aging |
SAE-AMS-DTL-23053.4.6.13 and ASTM D638 |
≥100%，23℃±2℃ |
|
Color Stability |
SAE-AMS-DTL-23053.4.6.15 |
175℃±2℃, 24h, Pass |
|
Dielectric Strength |
SAE-AMS-DTL-23053.4.6.13 and ASTM D2671 |
≥19.7kV/mm,23℃±2℃ |
|
Volume Resistance |
SAE-AMS-DTL-23053.4.6.13 and ASTM D876 |
≥1.0x1014Ω· cm,500V (DC),60s |
|
Flammability |
SAE-AMS-DTL-23053.4.6.14 and ASTM D2671 UL224 |
Self-extinguishing within 60s, ≤25% damaged area of print information, no dripping or large area falling |
|
Fluid Resistance |
AE-AMS-DTL-23053.4.6.11 |
No visual damage |
|
Print Persistence |
SAE-AS-81531.4.6.2 |
50 rubber erasure , identification |
|
Print Solvent Resistance |
MIL-STD-202G Method 215K |
10 rubber erasure , identification |
2:1 Ratio
|
Part Number |
As Supplied (mm) |
After Recovery(mm) |
Packing |
|||
|
ID(D) |
Flatten Width(w) |
Double Wall Thickness |
ID(d) |
Single Wall Thickness |
M/spool |
|
|
HSPT--2X-1.6- |
2.00±0.20 |
3.7±0.3 |
0.48±0.10 |
≤0.79 |
0.45±0.06 |
50 |
|
HSPT--2X-2.4- |
2.79±0.20 |
5.0±0.3 |
0.48±0.10 |
≤1.18 |
0.49±0.06 |
50 |
|
HSPT--2X-3.2- |
3.64±0.23 |
6.3±0.4 |
0.48±0.10 |
≤1.59 |
0.51±0.06 |
50 |
|
HSPT--2X-4.8- |
5.26±0.25 |
8.9±0.4 |
0.49±0.10 |
≤2.36 |
0.54±0.06 |
100 |
|
HSPT--2X-6.4- |
6.92±0.28 |
11.5±0.4 |
0.50±0.10 |
≤3.18 |
0.56±0.06 |
100 |
|
HSPT--2X-9.5- |
10.2±0.32 |
16.7±0.5 |
0.51±0.11 |
≤4.75 |
0.59±0.06 |
100 |
|
HSPT--2X-12.7- |
13.5±0.36 |
21.8±0.6 |
0.52±0.11 |
≤6.35 |
0.60±0.07 |
100 |
|
HSPT--2X-19.0- |
20.1±0.40 |
32.2±0.6 |
0.53±0.11 |
≤9.53 |
0.62±0.07 |
100 |
|
HSPT--2X-25.0- |
26.7±0.45 |
42.5±0.7 |
0.55±0.12 |
≤12.70 |
0.63±0.07 |
100 |
|
HSPT--2X-38.0- |
39.8±0.51 |
63.2±0.8 |
0.57±0.12 |
≤19.10 |
0.64±0.07 |
100 |
|
HSPT--2X-51.0- |
53.0±0.56 |
83.9±0.9 |
0.58±0.13 |
≤25.40 |
0.64±0.08 |
50 |
3:1 Ratio
|
Part Number |
As Supplied (mm) |
After Recovery(mm) |
Packing |
|||
|
ID(D) |
Flatten Width(W) |
Double Wall Thickness |
ID(d) |
Single Wall Thickness |
M/spool |
|
|
HSPT--3X-1.6- |
2.00±0.20 |
3.7±0.3 |
0.47±0.10 |
≤0.53 |
0.45±0.06 |
50 |
|
HSPT--3X-2.4- |
2.79±0.20 |
5.0±0.3 |
0.47±0.10 |
≤0.79 |
0.57±0.06 |
50 |
|
HSPT-3X-3.2- |
3.64±0.23 |
6.3±0.4 |
0.48±0.10 |
≤1.06 |
0.61±0.06 |
50 |
|
HSPT-3X-4.8- |
5.26±0.25 |
8.9±0.4 |
0.49±0.10 |
≤1.59 |
0.67±0.06 |
100 |
|
HSPT-3X-6.4- |
6.92±0.28 |
11.5±0.4 |
0.50±0.10 |
≤2.13 |
0.71±0.06 |
100 |
|
HSPT-3X-9.5- |
10.2±0.32 |
16.7±0.5 |
0.52±0.11 |
≤3.18 |
0.77±0.06 |
100 |
|
HSPT-3X-12.7- |
13.5±0.36 |
21.8±0.6 |
0.53±0.11 |
≤4.23 |
0.80±0.07 |
100 |
|
HSPT-3X-19.0- |
20.1±0.40 |
32.2±0.6 |
0.55±0.11 |
≤6.35 |
0.84±0.07 |
100 |
|
HSPT-3X-25.0- |
26.7±0.45 |
42.5±0.7 |
0.56±0.12 |
≤8.47 |
0.86±0.07 |
100 |
|
HSPT-3X-38.0- |
39.8±0.51 |
63.2±0.8 |
0.57±0.12 |
≤12.90 |
0.89±0.07 |
100 |
|
HSPT-3X-51.0- |
53.0±0.56 |
83.9±0.9 |
0.57±0.13 |
≤17.20 |
0.90±0.08 |
50 |
