Continuous operating temp of outside part ( silicone coating)

- 65 to +260°C

Continuous operating temp of braiding part( inner glass fiber )

550°C

Max short term exposure:

1650°C

Flame resistance:

VW-1

Dielectric strength

7-10 KV

Molten splash resistance:

Outstanding

Abrasion resistance:

Very good

Flexibility:

Outstanding

Water and oil resistance:

Outstanding

Model

Inner Dia.

Wall Thickness

Roll Length

 Part No.

mm

inch

mm

Meter

KFS-06

6

1/4

1.5

20

KFS-08

8

5/16

1.6

20

KFS-10

10

3/8

1.8

20

KFS-12/13

13

1/2

1.9

20

KFS-15

15

5/8

2.1

20

KFS-18

18

7/10

2.1

20

KFS-20

20

3/4

2.4

20

KFS-22

22

7/8

2.5

20

KFS-25

25

1

2.6

20

KFS-30

30

1 1/8

2.9

20

KFS-32

32

1 1/4

3

20

KFS-35

35

1 3/8

3.1

20

KFS-38

38

1 1/2

3.2

20

KFS-40

40

1 5/8

3.4

20

KFS-45

45

1 3/4

3.4

20

KFS-50

50

2

3.6

20

KFS-55

55

2 1/4

3.7

20

KFS-60

60

2 3/8

3.8

20

KFS-65

65

2 1/2

3.8

20

KFS-70

70

2 3/4

4

20

KFS-75

75

3

4.1

20

KFS-80

80

3 1/8

4.3

15

KFS-85

85

3 1/4

4.3

15

KFS-90

90

3 1/2

4.5

15

KFS-95

95

3 3/4

4.5

15

KFS-100

100

4

4.6

15

KFS-105

105

4 1/8

4.7

10

KFS-110

110

4 3/8

4.7

10

KFS-115

115

4 1/2

4.7

10

KFS-120

120

4 3/4

4.8

10

KFS-125

125

5

4.8

10

KFS-130

130

5 1/8

5

10

KFS-140

140

5 1/2

5.2

10

KFS-150

150

6

5.2

10
