FEP Tubing
Insutek FEP tubing is made from high quality FEP resin, it has great performance of heat resistance, acid resistance, alkali resistance, abrasion resistance, anti-sticking, UV resistance and high transparency, which is quite widely used in aerospace, chemical industry, medical equipment, power plant heat exchangers, steam piping etc.
Related products
Insutek FEP tubing is made from high quality FEP resin, it has great performance of heat resistance, acid resistance, alkali resistance, abrasion resistance, anti-sticking, UV resistance and high transparency, which is quite widely used in aerospace, chemical industry, medical equipment, power plant heat exchangers, steam piping etc.
Specifications Features
- UL 94V0 •Operate Temperature: –200 to 200°C
- Rohs, Reach •Low Temperature Flexibility
|
Item |
Unit |
Numerical Value |
|
Density |
g/cm3 |
2.15 |
|
Dielectric strength |
v/mm |
≥2000 |
|
Volume resistivity |
Ω.cm |
≥1018 |
|
Tensile strength |
Mpa |
19-22 |
|
Elongation |
％ |
≥250％ |
|
Flame resistance |
|
UL94V0 |
|
Using temperature |
℃ |
-20℃－+200℃ |
|
ID(mm) |
OD(mm) |
Wall Thickness (mm) |
Standard Packing |
|
2 |
3 |
0.5 |
500m |
|
2 |
4 |
1.0 |
500m |
|
3 |
5 |
1.0 |
500m |
|
4 |
6 |
1.0 |
500m |
|
5 |
7 |
1.0 |
500m |
|
6 |
8 |
1.0 |
500m |
|
7 |
9 |
1.0 |
500m |
|
8 |
10 |
1.0 |
500m |
|
9 |
11 |
1.0 |
500m |
|
10 |
12 |
1.0 |
500m |
|
11 |
13 |
1.0 |
500m |
